LW630.1-6-350 Wire Drawing Machine




Main Specifications

1.Max.strength to be drawn.
δb≥110kgf/mm2
2.Max.feed diameter.
2.5mm
3.Min.discharge diameter.
0.7mm
4.Drawing passes & block dia.
6/350
5.Average compressinn rate.
Approx.25% for low and medium carbon wire material
Approx.20% for high carbon wire material
6.Total compression rate (approx)
75% to 82%
7.Max.velocity of the full-loaded block
248m/min
8.Motor for machine proper
JZTy51.4L,N=7.5KW,n=1.200rpm Or Y160m-6,N=7.5KW,n=970rpm
9.Total weight of equipment.(approx)
7000
