Dry Type Wire Drawing Machines

1.  Usage: the set of machines is an ideal equipment drawing wire material of high, medium and low carbon steel , as well as copper,alumium and alloy, the machines are applied to drawing wire in the factories and nail making factory etc.

2.  Structure: the equipment consists consist of main reduction box ,die casing , wheel frame , wire brace and electrical control system . the spinning drawing blocks are driven by JZT or Y series motor ,with gear coupling runs changeful gears to reduce speed. The drawing blocks are vertically fixed in sealed box body , the gear pair are lubricated with oil.
In order to lower residual heat on the surface of the block ,the cooling means is installed in inter-wall of the block.

3. The machine runs with carwl or linkage. the safety halt gear is installed by the position of operation block.




Technical Specifications

Item

unit

Single Block Type

           Continuous Multi-block Type

Model



LD-1/800

LW- n/ 560

LW-n/450

LW-n/350

Max. drawing pass (n)





 n: 1 - 10

 n: 1 – 8

n: 1- 8

Tensile strength of wire rod

Kg/
mm2

-

>110

128

>140

max dia. of wire rod

mm

10-14

6.5

3.4

2.5

min dia. of finished wire

mm

6.0

2.5

1

0.75

Typical configuration

--

LD1-800

LW1- 6/560

LW1-7/450

LW1-6/350

max average reduction percent

%

25

30

20

21

designed total reduction percent

%

--

78-88.5

77.9

78

Max. speed of block

m/
min

0.4

245 (block. 6)

346.9 (block. 7)

200 (block 6)

Total power

kw

80

18.5-30

7.5-11

7.5-11

weight

kg

4500

2000

1500

1000

Overall dimensions

mm

3370x3340
x2020

1700x1150
x1750

1520x810
x1700

1400x800
x1500
